IDT RHR6
IDT-RHR6 is a compact and portable sled reader that is designed to provide hassle-free scanning of items, catering to the needs of various industries such as logistics, warehouse, manufacturing, retail, and asset tracking. It is compatible with both Android and iOS devices, making it a versatile choice for users. The device is built to deliver an exceptional reading range in UHF RFID application areas, and it boasts great reading and writing capabilities of over 10m thanks to its Impinj E710 Reader chips. This reader is perfect for those seeking a reliable and high-performance solution for their RFID needs. With its user-friendly design, it is easy to handle and deploy in any environment.x
Description
IDT RHR6
PHYSICAL PARAMETER
| Dimension | 143 x 76 x 140 mm | |||
| Weight | 483g | |||
| Touch Panel | Host Dependent | |||
| Phone Size Adaptibilty | Width 68~80 mm, thickness ≤ 22 mm | |||
| Interface | USB 3.0 Type-C | |||
| Battery | 5200 mAh (70 hours Standby, up to 6Hrs continuous use with UHF reading) | |||
| Alarm | Buzzer, LED Indication for Power, Work Bluetooth | |||
| Body | Plastic | |||
| Color | Black | |||
PERFORMANCE
| Processor | Cortex-M3 72MHz |
| Bluetooth | Bluetooth 4.0, BLE |
| Expansion | 64 MB RAM & 4 GB ROM |
ENVIRONMENTAL SPECIFICATIONS
| Temperature | -20°C to +50°C (Operating), -40°C to +70°C (Storage) |
| Humidity | 5% RH – 95% RH non condensing |
| Drop Test | Multiple 1.5 m drops to concrete |
| Sealing | IP 54 |
UHF RFID
| Frequency | 865-868 MHz |
| Antenna | Circular Polarized Antenna (3dBic) |
| Power | 1W (30dBm, support +5~+30dBm adjustable) |
| R/W Range | >10m |
| Reading Rate | up to 900 tags/sec. |
| Engine | Impinj R2000 |
OPTIONAL FEATURE
| Barcode | 1D & 2 D |
ORDER INFORMATION
| Part Number | IDT.RH.R6 |
