IDT RHC66
IDT RHC66, is a rugged portable mobile computer designed for reading NFC tags. Its industrial-grade build ensures durability and reliability in tough environments. With a powerful processor and stable wireless connection, this device is easy to deploy and helps increase productivity. The device is based on Android OS and supports quick charging, making it an efficient tool for businesses. It is also user-friendly and cost-effective, making it an ideal choice for various industries. With the IDT RHC66, businesses can easily streamline their operations and enhance their performance.
Description
IDT RHC66
PHYSICAL PARAMETER
| Dimensions | 160 x 76 x 15.5 mm | |||
| Weight | 287g | |||
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported | |||
| Display | 5.5-inch high definition full display (18:9), IPS LTPS 1440 x 720 | |||
| Battery | 4420 mAh (typ) / 4300 mAh (min) removable main battery | |||
| Keypad | 1 power key, 2 scan keys, 2 volume keys, 1 PTT key | |||
| Sensor | Gravity sensor, proximity sensor, light sensor, accelerometer sensor, vibration motor | |||
| Indicator LED | Power, charging, status indicator | |||
| Card Slot | 1 slot for SIM card, 1 slot for SIM or TF card | |||
| Interface | USB Type-C, USB 3.0, OTG, extended thimble | |||
| Camera | Rear 13 MP Autofocus with Flash | |||
ENVIRONMENTAL SPECIFICATION
| Temperature | -20 °C to +50 °C (Operating) -40 °C to +70 °C (Storage) |
|||
| Humidity | 5% RH – 95% RH non condensing | |||
| Drop Test | Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range | |||
| Tumble | 1000 x 0.5 m / 1.64 ft. falls at room temperature | |||
| Sealing | IP 65 | |||
PERFORMANCE
| Processor | Qualcomm 1.8 GHz Octa-core |
| RAM + ROM | 3 GB + 32 GB 4 GB + 64 GB (optional) |
| Expansion | Supports up to 128 GB Micro SD card |
COMMUNICATION
| Interface | WLAN, WWAN, Vo-LTE |
| Bluetooth | Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR |
| GNSS | GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna |
NFC
| Frequency | 13.56 MHz |
| Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2 |
| Chips | M1 card (S50, S70), CPU card, NFC tags, etc. |
OPTIONAL FEATURES
| RFID | UHF (865-868 MHZ – EPC C1 GEN2 / ISO18000-6C) |
| Barcode | 1D&2D |
| Accessories | Separate handle with one button, Handle + battery (handle battery 5200 mAh, one button), UHF back clip + handle (5200 mAh, one button), Wrist Strap; Rubber Bumper; Charging Cradle |
ORDER INFORMATION
| Part Number | IDT.RH.C66 |
