PHYSICAL PARAMETER

Dimensions	108 x 78 x 18mm
Weight	200g
Interface	Type C USB & Bluetooth 4.0
Battery	2000 mAh
Keypad	On/Off & Scan
Alarm	LED indication for Charging, Battery & Bluetooth
Phone Connectivity	With any Android & iOS device
Color	Black
Body	Plastic

ENVIRONMENTAL SPECIFICATION

Temperature	-20 °C to +50 °C (Operating) -40 °C to +70 °C (Storage)
Humidity	5% RH – 95% RH non condensing
Drop Test	1.2 m dropping on concrete
Protection	IP 54

UHF RFID

Frequency	865-868 MHz
Engine	CM710-1 module based on Impinj E710
Antenna	Circular Polarized Antenna (4 dBi)
Power Output	1W (30dBm, support +5~+30dBm adjustable)
R/W Range	> 9 m
Reading Rate	900+ tags/sec

OPTIONAL FEATURES

SDK	Android / IOS SDK Supported
Security	RFID Encrypted Module (Reserve)

ORDER INFORMATION

Part Number

IDT.RH.R5
