IDT RHC5
IDT RHC5 is an upgraded all-in-one high-performance android-based rugged portable scanner specially designed for hassle-free scanning of items. The device is Integrated with a self-developed Impinj E710/R2000-based UHF module which offers industry-leading UHF performance featuring the Android 11 platform, Qualcomm octa-core processor, optional mass internal memory, and a large capacity removable battery. IDT RHC5 also supports 2D scanning, NFC, fingerprint recognition, and other functions, which enables it to be widely used in the application areas like warehousing, retail, logistics, banking, public security, and other industries.
Description
IDT RHC5
PHYSICAL PARAMETER
| Dimensions | 177.0 x 80.2 x 14.8mm | |||
| Weight | 626g | |||
| Interface | USB 2.0 Type-C, OTG, Type-C headphones supported | |||
| Battery | 6700mAh removable pistol battery Built in 100mAh backup battery, supporting battery hot swap | |||
| Keypad | 1 power key, 2 scan keys, 1 user-defined key, 2 volume keys (+/-) | |||
| Display | 5-inch (Fingerprint), 1280 x 720 / 6-inch, 2400 x 1080 | |||
| Touch Panel | Multi-touch panel, gloves and wet hands supported | |||
| Audio | 2 microphones, 1 for noise cancellation; 1 speakers; 1 receiver | |||
| Notification | Sound, LED indicator, vibrator | |||
PERFORMANCE
| Processor | Octa-core, 2.3GHz |
| Expansion | Supports up to 256GB Micro SD (TF) card |
| RAM+ROM | 3GB + 32GB (RAM + ROM) 4GB + 64GB (Optional) |
ENVIRONMENTAL SPECIFICATION
| Temperature | -20 °C to +50 °C (Operating) -40 °C to +70 °C (Storage) | |||
| Humidity | 5% RH – 95% RH non condensing | |||
| Drop Test | 1.5 m to the concrete | |||
| Protection | IP65 | |||
COMMUNICATION
| WLAN | 802.11 a / b / g / n / ac, 2.4G / 5G dual-band | |||
| WWAN | 2G, 3G & 4G | |||
| Bluetooth | 5.0 | |||
| Vo-LTE | Support | |||
| GNSS | GPS / AGPS, GLONASS, BeiDou, Galileo | |||
UHF RFID
| Frequency | 865-868 MHz / 920-925MHz / 902-928MHz |
| Engine | CM710-1 module based on Impinj E710 Impinj Gen2X Supported |
| Antenna | Circular polarization; 5dBic |
| Power Output | 1W (30dBm, +5dBm to +30dBm adjustable) 2W Optional (33dBm, for Latin America, etc.) |
| Protocol | EPCglobal Gen 2 (ISO18000-6C) |
| Reading Rate | 950+ tags / sec (Circular Polarized) |
CAMERA
| Front Camera | 5MP |
| Rear Camera | Rear 13MP Autofocus with flash |
Developing Support
| SDK | Android / IOS SDK Supported |
| Operating System | Android 11/13 |
| Language | Java |
| Tool | Eclipse / Android Studio |
ORDER INFORMATION
| Part Number | IDT.RH.C5 |
