IDT RHC66
IDT RHC66, is a rugged portable mobile computer designed for reading NFC tags. Its industrial-grade build ensures durability and reliability in tough environments. With a powerful processor and stable wireless connection, this device is easy to deploy and helps increase productivity. The device is based on Android OS and supports quick charging, making it an efficient tool for businesses. It is also user-friendly and cost-effective, making it an ideal choice for various industries. With the IDT RHC66, businesses can easily streamline their operations and enhance their performance.
Description
IDT RHC66
PHYSICAL PARAMETER
| Dimensions | 160 x 76 x 26 mm | |||
| Weight | 297g | |||
| Touch Panel | Multi-touch panel, gloves and wet hands supported | |||
| Display | 5.5-inch high definition full display (18:9), IPS LTPS 1440 x 720 | |||
| Battery | Removable main battery 5200mAh, support QC3.0 and RTC
Standby: up to 490 hours |
|||
| Keypad | 1 power key, 2 scan keys, 2 volume keys | |||
| Sensor | Gravity sensor, proximity sensor, light sensor, accelerometer sensor, vibration motor | |||
| Indicator LED | Power, charging, status indicator | |||
| Card Slot | 1 slot for SIM card, 1 slot for SIM or TF card | |||
| Interface | USB Type-C, USB 3.0, OTG, extended thimble | |||
| Camera | Rear 13 MP Autofocus with Flash | |||
ENVIRONMENTAL SPECIFICATION
| Temperature | -20 °C to +50 °C (Operating) -40 °C to +70 °C (Storage) |
|||
| Humidity | 5% RH – 95% RH non condensing | |||
| Drop Test | 1.8 m to the concrete | |||
| Tumble | 1000 x 0.5 m / 1.64 ft. falls at room temperature | |||
| Sealing | IP 65 | |||
PERFORMANCE
| Processor | Qualcomm 1.8 GHz Octa-core |
| RAM + ROM | 3 GB + 32 GB 4 GB + 64 GB (optional) |
| Expansion | Supports up to 256 GB Micro SD (TF) |
COMMUNICATION
| Interface | WLAN, WWAN, Vo-LTE |
| Bluetooth | 5.1 |
| GNSS | GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna |
UHF RFID
| Frequency | 865-868MHz / 920-925MHz /902-928MHz |
| Protocol | EPCglobal Gen2 (ISO18000-6C) |
| Read Range | 2.7m |
OPTIONAL FEATURES
| NFC | 13.56 MHz |
| Barcode | 1D&2D |
| Accessories | Separate handle with one button, Handle + battery (handle battery 5200 mAh, one button), UHF back clip + handle (5200 mAh, one button), Wrist Strap; Rubber Bumper; Charging Cradle |
ORDER INFORMATION
| Part Number | IDT.RH.C66 |
ID Tech is a manufacturer, provider, seller, and distributor of a wide range of NFC, Bluetooth, HF, UHF, RFID handheld, and fixed readers. Provides a comprehensive range of RFID Handheld Readers for a variety of industries. We have excellent working knowledge of LF( Low Frequency ), HF( High Frequency ), and UHF( Ultra High Frequency). In addition to our top-of-the-line hardware offerings, ID Tech Solutions also provides a comprehensive suite of RFID management software. Our team of skilled developers has extensive experience in designing software. From inventory management to asset tracking, our software solutions are tailored to meet the specific needs of each client, ensuring seamless integration and maximum efficiency. We have deployed our solutions in a range of highly specialized vertical markets that include Coal Mines, Toll Roads, Airports, Hotels, Railway Stations, Libraries, Hospitals, Textile Manufacturing, Automotive, Fashion, Apparel, Hospitality, and others.
