IDT RHP80
ID Tech offers the IDT RHP80 RFID tablet, which is integrated with the industry’s best-in-class Impinj E710/R2000 module. This rugged device offers exceptional reading performance of over 10m and features an 8-inch display. Powered by a QUALCOMM processor, the IDT RHP80 offers excellent performance, making it suitable for a variety of applications. Equipped with the latest technology, the IDT RHP80 RFID tablet offers a cost-effective solution for businesses looking to improve their operations. Its user-friendly interface and versatility make it easy to integrate into existing systems and processes, allowing for seamless implementation. With its exceptional performance and durability.
Description
IDT RHP80
PHYSICAL PARAMETER
| Dimensions | 250.8 x 152.0 x 15.0 mm | |||
| Weight | 680 g | |||
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported | |||
| Display | 8” IPS LTPS 1920 x 1200 / IPS LTPS 1280 x 800 | |||
| Interface | USB 2.0 Type-C, OTG | |||
| Battery | 8000 mAh | |||
| Alarm | Audio & Visual | |||
| Expansion Slot | 1 slot for SIM card, 1 slot for SIM / TF card, Optional dual PSAM card slots | |||
| Keypad | 1 front key, 1 volume key, 1 power key, direction key (optional) | |||
| Sensor | Gravity sensor, gyroscope, accelerometer sensor, light / proximity sensor | |||
PERFORMANCE
| Processor | Octa-Core 2.0 GHz; GMS&AER |
| Expansion | Supports up to 256 GB Micro SD card |
| Memory | 3 GB + 32 GB / 4 GB + 64 GB (Optional) |
ENVIRONMENTAL SPECIFICATIONS
| Temperature | -20°C to +50°C (Operating), -40°C to +70°C (Storage) |
| Humidity | 5% RH – 95% RH non condensing |
| Drop Test | Multiple 1.5m to the concrete |
| Protection | IP 65 |
COMMUNICATION
| Bluetooth | Bluetooth 5.1 |
| WLAN | Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6; |
| WWAN | 2G, 3G & 4G |
| GNSS | GPS/AGPS, GLONASS, BeiDou,Galileo, internal antenna |
| Vo-LTE | Support Vo-LTE HD video voice call |
UHF RFID
| Frequency | 865-868 MHz EPC C1 GEN2 / ISO18000-6C |
| Antenna | Circular polarization (4dBi) |
| Engine | CM2000-1 module based on Impinj Indy R2000 |
| R/W Range | Up to 10 m (open outdoors, Impinj MR6 tag) |
| Reading Rate | 900+tags/Sec |
| Power | 1W (30dBm, +5dBm to +33dBm adjustable) |
OPTIONAL FEATURE
| Barcode | 1D & 2D |
| Fingerprint | Fingerprint enrollment, match, storage etc. |
| PSAM | 2 PSAM slots (maximum) |
| NFC | 13.56 MHz (0-4cm) |
ACCESSORIES
| Standard | AC Adaptor, USB Cable, Lanyard. |
| Optional | Cradle, Holster |
DEVELOPING SUPPORT
| Operating System | Android 13; GMS&AER, 90-day security updates, FOTA, Soti Mobicontrol, SafeUEM supported |
| Language | Java |
| SDK | Provided |
| Tool | Eclipse / Android Studio |
CAMERA
| Rear Camera | 13 MP Autofocus with flash |
| Front Camera | 8 MP |
ORDER INFORMATION
| Part Number | IDT.RH.P80 |
