UHF GATE READER
IDT RFID UHF Portal is a compact RFID Gate specially designed for superior reading performance in harsh industrial environments. It’s ergonomic design makes it ideal for Inventory Management, Asset Management, Logistics, Manufacturing, Retail, Hospitals, and Libraries. It has Red & Green LED Lights that indicate Standby Mode and Inventory Mode . The High-performance portal is meant for use in doorways, hallways, or access points, and can also provide general zone coverage, for application in offices, institutions such as healthcare facilities, retail, or attendance or access control applications and is ideal for monitoring pallets, assets, equipment, files or people.
Description
UHF GATE READER
ID Tech Solutions provides an indigenously built UHF RFID Portal, can be used for an advanced management system for automation in the Libraries, Retail, Warehouses, Offices, Schools or Universities for Attendance Management system etc. Typically mounted at the entrance and/or exit of a location, the gate reader confirms or updates the material status automatically as it arrives or departs. The UHF Gates function along with with UHF ID cards or IDT UHF Passive Tags as a walk through solution for Automatic Time & Attendance; this eliminates the need for flashcards, which saves time and energy and makes the process more convenient.
PHYSICAL PARAMETERS
| Dimension | 182cm x 304cm x 152cm |
| Weight | 18 Kg |
| Indicators | Buzzer & LED |
| Housing | Cold Rolled Steel & Aluminuium |
ENVIRONMENTAL SPECIFICATION
| Temperature | -25oC to +60oC (Operating), -25oC to +80oC (Storage) |
| Humidity | 5% RH – 95% RH non condensing |
| Protection Class | IP 54 |
UHF RFID
| Work Frequency | Standard ISM 865-868, 902 – 928 Mhz (Customizable) | |||
| Protocol | ISO 18000-6B, EPC Class 1 Gen2 (ISO 18000-6C) | |||
| Read Range | 3 Cubic Meter | |||
| No. of Towers | 2 | |||
| Antenna | Built in 9 dBi Circular Polarized Antenna | |||
| Operating Mode | Answer | |||
| Reading Rate | Software Programmable | |||
| Power Output | 0-30 dBm (adjustable) | |||
| Packing | In wooden Box | |||
| Power Supply | 100-240V, DC+9V (Power Adapter) | |||
| Power Consumption | 1 W | |||
| Interfaces | RS232, RS485, TCP/IP (Wi-Fi Optional ) | |||
| Software Support | SDK Provided | |||
OPTIONAL
| Display | Integrated 10″ Touchscreen |
| Height | 215cm |
| LED Red | Standby Mode |
| LED Green | Inventory Mode |
ORDER INFORMATION
| Part Number | IDT.GR.UHF |
ID Tech Solutions is a prominent manufacturer, provider, seller, and distributor of a wide range of NFC, Bluetooth, HF, UHF, RFID handheld, and fixed gate readers. Providing a comprehensive range of RFID Fixed Readers for a variety of industries. We have an excellent working knowledge of LF (Low Frequency), HF (High Frequency), and UHF (Ultra High Frequency). Our team is well equipped to design RFID management software to work seamlessly in the most demanding environment. We have deployed our solutions in a range of highly specialized vertical markets that include Coal Mines, Toll Roads, Airports, Hotels, Railway Stations, Libraries, Hospitals, Textile Manufacturing, Automotive, Fashion, Apparel, Hospitality, and others. With our extensive research and development capabilities and manufacturing facilities, all ID Tech products meet the highest international quality standards. To know more, contact us.
